OV5645-AF-V1.0 HD Wide Angle MIPI Monitoring Module CMOS 5MP Scan Code FPC Camera Module
Item TBD06032375
Warehouse: CN
Lead time: Item will be ready for ship between 04 Oct and 06 Oct 2024
Description
1. Support anti-shake, can be applied to cell phones, smart toys, PC multimedia, digital cameras, law enforcement, sports cameras, smart home, intelligent identification, car recorders, etc.
2. OV5645 light-sensitive chip, high image quality, low noise, high sensitivity, low crosstalk, low power consumption
3. Autofocus, with motor, support autofocus control AF VCM driver
4. 5 megapixels, 2592x1944 resolution, support 1080P@30fps, support 720P 60 fps high-speed shooting
5. Pixels: 5.0 megapixels (2592x1944)
6. Light-sensitive chip: OV5645 (1/4 inch) CMOS
7. Format: RGB/YUV
8. Frame rate: QSXGA (2592x1944): 15 fps; 1080p: 30 fps; 1280x960: 45 fps; 720p: 60 fps
9. Interface: MIPI
10. Field of view/focal length: 67.4 degrees/3.37mm
11. Size: about 21 x 8.5 x 5mm
