COMFAST CF-E355AC 1200Mbps Dual Band Wireless Indoor Ceiling AP 2.4G+5.8GHz WiFi Access Point

Description

Features
1. Two Qualcomm chips, stable performance
2. 1200Mbps dual-band, Gigabit Ethernet port
3. 48V standard POE power supply, remote power supply
4. Support users 120+(max)
5. Memory 128M, flash memory 16M
6. Transmit power 500mW (max)

Specification
1. Hardware Specifications:
Qualcomm, QCA9531+QCA9886 chip solution
Memory: 128MB
Flash: 16MB
Power amplifier chip: 2.4G SE2576L, 5.8G SKY85728-11
Configure the watchdog chip
2. Antenna specifications: built-in hardware smart antenna system, gain 3dBi
3. Wireless speed: 2.4GHz: 300Mbps/5GHz: 867Mbps
4. RF parameters:
Transmit power: 500mW (27dBm)
Receive sensitivity: -96dBm
Operating frequency: 802.11ac/n/a: 5.18GHz-5.825GHz, 802.11b/g/n: 2.412GHz-2.4835GHz
5. Modulation technology:
DSSS: DBPSK@1Mbps, DQPSK@2Mbps, CCK@5.5/11Mbps
OFDM: DBPSK@6/9Mbps, QPSK@12/18Mbps, 16-QAM@24Mbps, 64-QAM@48/54Mbps, 256-QAM@433Mbps
MIMO-OFDM(11n): MCS 0-23
MIMO-OFDM(11ac): MCS 0-29
6. Physical interface:
1 10/100Mbps WAN RJ45 port, support POE power supply
1 10/100Mbps LAN RJ45 port, support POE power supply
1 RESET reset button
7. Indicator light: 1 tri-color indicator light
8. Power supply:
Power supply mode: POE power supply, support 802.3af/802.3at standard (less than or equal to 100 meters)
Power adapter: 48V 0.32A POE power adapter
9. Power consumption: less than 13W
10. Shell material: ABS
11. Dimensions: 220 x 220 x 45mm
12. Weight: 0.37kg
