XL4005 DC-DC Adjustable Buck Power Module 5-32V High Power
Item TBD0603862501
Warehouse: CN
Lead time: Item will be ready for ship between 25 Nov and 26 Nov 2024
Description
1. Use high power magnetic surround inductor and high current control chip, small size, high power, high efficiency
2. Application areas: DIY mobile power, car power supply, communication equipment power supply, etc.
3. Module nature: non-isolated buck
4. Rectification mode: non-synchronous rectification
5. Input voltage: 5V-32V
6. Output voltage: 0.8V-24V
7. Conversion efficiency: up to 90
8. Switching frequency: 300KHz
9. Output ripple: 30mV (no load)
10. Load regulation rate: about 0.5%
11. Voltage regulation rate: about 2.5%
12. Operating temperature: -40 - 85 degrees Celsius
13. External Dimensions: Approx. 4.3 x 2.1 x 1.4cm
