NK-M008 3G / SDI to HDMI Full HD Converter(Black)

Description

1. Support HD-SDI and 3G-SDI
2. Support full HD 1080P@60Hz
3. Automatic resolution recognition
4. One way SDI loopback output
5. Audio and image sync output
6. Easy to install

Specification

Package Contents

1 x Converter, 1 x Power Adapter, 1 x User Manual

Input Port

1 x BNC (SDI/HD-SDI/3G-SDI)

Output Port

1 x BNC (SDI/HD-SDI/3G-SDI), 1 x HDMI

SMPTE Standard

425M Level A & B, 424M, 292M, 259M-C

SDI Transmission Rates

2.970 Gbit/s and 2.970/1.001 Gbit/s

Power Supply

DC 5.0V / 2.0A

Working Current

500mA(Max)

Operating Temperature

-15-55 Degree Celsius

Operating Humidity

5 ~ 90 Percent RH (No condensing)

ESD Protection Human Body Model

+-8kV (air-gap discharge), +-4kV (contact discharge)

Size

10cm x 6.5cm x 2.5cm

Weight

250g
