Features
1. IP67, 10 years warranty
2. Remote WIFI Module built inside as standard, intelligent monitoring and management
3. Smart APP can realize real-time data transmission
4. Individual MPPT power automatic tracking with max efficiency up to 99.5%
5. Large production capacity, faster delivery ( 25-35 days for mass production).
6. High reliability and efficiency up to 96.5%
7. Support parallel operation
Specifications
1. Model: RTW-600pro-EU
2. Commonly used module power (W): 210 to 455W (2 Piece)
3. Maximum input voltage (V): 60V
4. MPPT voltage range (V): 25~55V
5. Start-up voltage (V): 25V
6. Maximum input current (A): 2 x 13A
7. Maximum input short circuit current (A): 2 x 19.5A
8. Rated output power (VA): 600W
9. Rated output current (A): 2.7A
10. Nominal frequency/range (Hz): 50/48~52Hz or 60/58~62Hz
11. CEC peak efficiency: 96.50%
12. Nominal MPPT efficiency: 99.9%
13. Night power consumption (mW): Less than 50mW
14. Enclosure rating: IP67
15. Number of MPPTs: 2
16. Number of Inputs per MPPT: 1
17. Communication: WiFi
18. Compliance: EN 50549-1: 2019, VDE-AR-N 4105: 2018, IEC/EN 62109-1/-2, IEC/EN 61000-6-1/-2/-3/-4, IEC/EN 61000-3-2/-3
