i2C C07 Locksmith No.1 Remote Control Frequency Tester Multimeter, Plug: EU Plug(Configuration 1)

Description

1. Frequency test/Current testing/Waveform Measurement/Remote control repair/Diode measurement/Soldering iron function
2. No need for complicated code matching. just one click and it will respond! Can test infrared 433/315/868/902 frequency remote contro. Triggering the light is simple and clear
3. Voltage/current/resistance/on/off/diode/capacitance frequency can be solved by one machine, covering all maintenance and inspection
4. Ultra-fast diode measurements
5. High-speed scanning and accurate measurement, Buzzer mode, diode mode, 2 in 1, extremely simple operation
6. Can measure 0-40VDC DC voltage and has 20 sets of data recording function |considerate and more practical

Specification:
1. Host adapter input voltage: AC110–230V
2. Remote maintenance output voltage: 3V / 6V / 9V / 12V
3. Remote maintenance output current: 0–300mA
4. Remote maintenance current accuracy: 0.1 Microampere
5. Banana plug input voltage: DC 0–30V
6. Banana plug input detection current: 0–8A
7. Soldering station input voltage and current: DC 24V 5A
8. Product dimensions: 118.8 × 97 × 31.5mm
9. Screen size: 4.0 inch
10. Screen resolution: 320 × 480
11. Diode test: 0–2.8V
12. Resistor budgeting: 0–50K
13. DC voltage measurement: 0–30V+ -
